All available at my new shop!
We offer ready-to-go hydraulic autosteer kits, as well as individual components, surveying equipment and hydraulic valves.
Our pre-made autosteer kits are easy to install, and all of the electronics and software have been taken care of by us. Simply make up a couple of brackets and hydraulic hoses, then get straight to calibration!
All autosteer kit orders in a new area to us will receive a FREE RTK base station, and one RTK stream.
We ship worldwide.
Have you got a wiring diagram for the hydraulic valve into an all in one 4.5 board with an ampseal plug?
Left/right and lock straigt to the corresponding pins on the ampseal . 3 plugs on the valve and all the earths get put together so 3 earths then left right and lock power
As @del_boy said:
Pin 5 and GND to the left coil
Pin 6 and GND to the right coil
Pin 7 and GND to the safety lock coil
It’s a shame the ampseal doesn’t have many spare GND connections so it’s a little more difficult than just plugging in 6 pins, but it’s still pretty easy to do. I include the DT06 plugs and crimps for the valve end of the equation.
What flow rate is the hydraulic load sense valve rated for? Can the safety switch be removed?
